Input voltage: AC24V(± 10%), 50/60Hz

Power consumption: Heater ≤ 60W Fan ≤ 2W

IP standard: IP66

Automatic temperature control:

Heater:

On: 5 ± 5

Off: 15± 5

Fan:

On: 40± 5

Off: 25± 5

Mode of opening upper cover: Top-opened gas spring knighthead

Material:

Body: Aluminum alloy

Viewing window: Optical glass

Lock catch: Stainless steel

Operating ambient temperature: -35 to 65(with Heating elements)

Operating ambient humidity: <90%(without condensing agent, under heating conditions)

Viewing window: 75 (W)X 70(H)mm, double window

Maximum size of equipment installation:

Both sides of the space: 200(L) X 75(W) X 100(H)mm

Recommend pan tilt: J-PT-2118-D, J-PT-2215-DL

Optional: Heater, fan, sunshield and wiper

Installation environment: Outdoor

Weight: 3.85kg
