Optional visible light cameras, thermography, infrared lights, laser device

Built-in adjustable mounting slide plate

Built-in heater&fan auto temperature control circuit

Provides protection from dust and water, anti-corrosion, heat-resistant, suitable for all-weather outdoor environment

Technical data:

Input voltage: AC24V(± 10%) 50/60Hz

Power consumption: Heater≤ 60W Fan ≤ 2W

Automatic temperature control

Heater Open: 5º C± 5º C Close: 15º C± 5º C

Fan Open: 40º C± 5º C Close: 25º C± 5

Open mode: Back-opened

Material Body: Aluminum alloy/Viewing window: Optical glass

Operating ambient temperature: -35º C~+65º C(with Heating elements)

Operating ambient humidity: <90%(without condensing agent, under heating conditions)

Maximum size of camera installation: 550mmX188mmX140mm

Both sides of the space: 720mmX280mmX207mm

Recommend pan tilt: J-IP-7240-DL; J-IP-4250-DL

Installation environment: Indoor and outdoor

IP standard: IP66
