Supports many kinds of camera, bare machine and integrated machine

Tour through presets in groups

With OSD function

Supports manual zoom

Keying and manual control/auto-focus

Automatic iris

Supports network camera

Inner mount preventing from surge or lightning

Pelco-P or Pelco-D protocol: identified automatically

With activity function

RoHS approved

Suitable for Sony, CNB, and SDM cameras

Technical data:

Voltage: 12V DC ±15% (linear power)

Pan speed: 0.9 to 48/s

Tilt speed: 0.9 to 26/s

Pan scale: 360°, continuously

Tilt scale: 0.9 to 90° (manual)

Suitable temperature: -30 to 50°C (outdoor)

Preset number: maximum 128, programmable

Communication format standard: RS-485 (BUS)

Power on: wait for commands after self-testing

Mechanism structure: built-in PTZ

Band rates: 2,400, 4,800 and 9,600bps
