360° continuous pan

89° in tilt

180° in auto-flip

Maximum of 128 presets, programmable

3D scan between two presets

OSD function

Manual zoom

Need to add zoom lens

Camera data setup function

Tours through presets in groups

Pelco-P/Pelco-D protocol is identified automatically

Activity/auto-park functions

Built-in prevention from surge or lightning strike

Easy to install

Connects electron components fast and simply

Auto information protection function is on when power cutting

Compliant with the RoHS Directive

Tamper design

Technical data:

Voltage: 24V AC ±15%

Mechanism power: ≤24W

Pan/tilt speed: 0.1 to 120°/s

Manual tilt scale: 1 to 90°

Pan scale: 360° continuously

Suitable temperatures: -10 to 50°C (indoor)

Humidity: ≤95% RH

Preset number: 128 maximum

Preset found time: : ≤1.5 seconds

Preset speed:

Pan: 600°/second

Tilt: 480°/second

Zoom speed: manual

Scan precision: 0.1 ± 0.03°

Signal formats: PAL/NTSC

Preset precision:±0.3°

S/N ratio: greater than 48dB

Communication format standard: RS-485 (bus)

Power on: wait for commands after self-testing

Mechanism structure: U

Housing material: high-intensity and aging-resistant PC

Housing colors: black, gray, argent and ultramarine

Baud rate: 2,400, 4,800 and 9,600bps
