Optional visible light cameras, thermography, infrared lights, laser device

Built-in adjustable mounting slide plate

Built-in heater & fan auto temperature control circuit

Provides protection from dust and water, anti-corrosion, heat-resistant, suitable for all-weather outdoor environment

Technical data:

Input voltage: AC 24V (±10%) 50/60Hz

Power consumption: Heater ≤60W/Fan ≤2W

Automatic temperature control: Heater open: 5℃±5℃, Close: 15℃ ±5℃

Fan open: 40℃ ±5℃, Close: 25℃ ±5℃

Open mode: Back-opened

Material: Body: aluminum alloy/viewing window: optical glass

Operating ambient temperature: -35-65℃ (with heating elements)

Operating ambient humidity: ＜90%(without condensing agent, under heating conditions)

Maximum size of camera installation: 550x188x140mm

Both sides of the space: 720x280x207mm

Recommend pan tilt: J-IP-7240-DL/J-IP-4250-DL

Installation environment: Indoor and outdoor

IP standard: IP66
