Double layer design, 355° panning, 90° tilting

Mechanism can be installed easily

Housing can choose 7, 9 and 12 inches (indoor) for all-weather, upper housing is made of high-intensity ABS material, waterproof, anti-aging and anti-cauterization

Pan and tilt unit angle can be adjustable

Built-in decoder, can identify Pelco-P, Pelco-D, AD and Panasonic protocol, can follow client’s request

Pan/tilt can change direction easily

Self–testing when power on

Auto-tour through function

Can match Sony/CNB/SDM/Panasonic camera

Technical data:

Voltage: 24V AC, ± 10%

Power consumption: ≤24W (outdoor)

Pan scale: 0 to 355°

Tilt scale: 0 to 90°

Pan speed: 12°

Tilt speed: 12°

Suitable temperature: -10 to 50°C (indoor)

Communication format standard: RS485 bus

Address scale: 0 to 255

Preset number: 51

Power-on waiting command after self-testing

Mechanism structure: built-in pan and tilt

Built-in protocol Pelco-P or Pelco-D can be identified automatically

Baud rates: 2,400, 4,800 and 9,600bps
