High-intensity aluminum alloy material, enhanced capability of impact resistance, shielding and heat dissipation

Suitable for the environment such as high temperature, dustiness and nights lacking of lighting

Precise stepping motor drive, with sensitive reaction, stability and reliability, equipped with disassembled protection device

All weather environment design, protection grade IP66

Features:

High-intensity aluminum alloy, enhance the heat emission ability

Adopts high-power IR light, with shinning distance 100m, the IR light can also be replaced with laser light

Manual close and open the IR light

360° continuous pan, 90° in tilt and 180° auto-flip

Maximum of 128 presets, programmable

Auto-pan scan (360° continuous cruise and cruise between A and B)

Three-dimensional scan between two presets

Call menu function

Manual control zoom function

Manual/auto-focus/iris/white balance/BLC

Tour through presets in groups

Variable tour speed and dwell touring time

Standard RS-485 communication format

Built-in Pelco-P or -D protocol

Automatic error correction function

Fast address function (with ID number)

Proportion zoom function (auto-match focal length/operating speed)

Technical specifications:

Supply voltage: DC 24 ± 5V

Supply current: ≥2A

Power consumption: 6 to 28W

IR shinning distance: 100m

Pan turn speed: 0.1 to 300°/s (manual)

Tilt turn speed: 0.1 to 200°/s (manual)

Pan turn scale: 360° continuous pan

Tilt turn scale: 0 to 90°

Working temperatures: -20 to 50°C (non-condensing)

Communication format: standard RS-485

Address range: 0 to 256

Preset number: 110 (maximum)

Preset precision: ±0.1°

Positioning accuracy: ±0.1°

Built-in protocol: auto identify Pelco-P or -D

Baud rate: 1,200/2,400/4,800/9,600bps (optional)

Housing material: high-intensity aluminum alloy

Weight: 3.8kg
