Input voltage: AC24V(±10%),50/60Hz

Power consumption: Heater ≤60W Fan ≤2W

IP standard: IP66

Automatic temperature control:

Heater:

On: 5 ±5℃

Off: 15±5℃

Fan:

On: 40±5℃

Off: 25±5℃

Mode of opening upper cover:Top-opened gas spring knighthead

Material :

Body: aluminum alloy

Viewing window: optical glass

Lock catch: stainless steel

Operating ambient temperature: -35 to 65℃(with Heating elements)

Operating ambient humidity: ＜90%(without condensing agent, under heating conditions)

Viewing window: 75 (W)x 70(H)mm,double window

Maximum size of equipment installation:

Both sides of the space: 200(L) x 75(W) x 100(H)mm

Recommend pan tilt: J-PT-2118-D, J-PT-2215-DL

Optional: heater, fan, sunshield and wiper

Installation environment:Outdoor

Weight：3.85kg
