360 degrees continuous pan

90 degrees in tilt

180 degrees in auto-flip

Maximum 128 presets, programmable

Board camera is available, the range of visual angle capture is wide

Three-dimensional scan between two presets

OSD function

Manual zoom

Need to add zoom lens

Camera data setup function

Tours through presets in groups

Pelco-P/-D protocol is identified automatically

Activity function

Auto-park function

Built-in prevention from surge or lightning strike

Easy to install

Connects electron components fast and simply

Auto information protection function is on when power cutting

RoHS design

Tamper design

Technical data:

Voltage: 12V AC (±15%)

Mechanism power: ≤7W

Pan/tilt speed: 0.1 to 120°/second

Manual tilt scale: 1 to 90°

Pan scale: 360° continuously

Suitable temperature: -10 to 45°C (indoor)

Humidity: ≤ 90%

Preset number: maximum 128

Preset found time: ≤ 1.5 seconds

Preset speed:

Pan: 600°/second

Tilt: 480°/second

Zoom speed: manual

Scan precision: 0.1 ± 0.03°

Signal format: PAL/NTSC

Preset precision: ± 0.3°

S/N ratio: grater than 48dB

Communication format standard RS-485 (bus)

Addressed scale: 0 to 63

Power on: wait for commands after self-testing

Mechanism structure: U

Housing materials: high-intensity PC material and aging-resistance

Housing colors: black, gray, argent and ultramarine

Built-in protocol: Pelco-P/D protocol is identified automatically

Baud rate: 2,400, 4,800, and 9,600bps

Weight:1kg
