1.With 6-inch cover

2.Designed for indoor environment, upper housing is made of high-intense flame retardant ABS material, anti-aging, anti-high temperature, and anti-cauterization

3.360 degrees continuously pan, 90 degrees in tilt, and 180 degrees in auto flip

4.Auto pan scan: Horizontal scan automatically, three-dimensional scan between two presets

5.Call OSD function by manual

6.Menu call and zoom manually

7.Unique ID, can achieve remote address control

8.Tour through preset in groups,can apart into 4 groups ,max 32 presets in each group.

9.Tour speed is adjustable;Dwell time is changeable

10.Pelco P or D can be indentified automatically

11.Activity functions:Auto park function

12.Restore function, auto protection is on when power is cutting

13.Privacy zone function (applied to 1 to 18C, S1 to 18B, H23BW, and S3 series camera)

14.Proportional controlling function

Hold looking function

Technical data:

Voltage: 24V AC (±10 %)/12V DC (±10 %)

Consume voltage:

Outdoor: ≤30W (including auto temperature control function)

Indoor: ≤20W

Turn speed:

Pan: 0.1 to 240°/s, (manual) call preset 240°/s

Tilt: 0.1 to 120°/s (manual) call preset 120°/s

Turn scale:

Continuously pan: 360°

In tilt: 90 °

Work temperature:

Outdoor: -35 to 50°C (no condensation)

Indoor: -10 to 50°C (no condensation)

Communication format: standard RS485 (mians) (half duplex)

Baud rate: 1,200/2,400/4,800/9,600bps

Weight: 2kg
