Powerful function, human menu setup

Speedy focus and catch targets

Point security technical, age-resistant, high-effectiveness and high-ray length

More than 120m infrared ray dark distance

Optional wiper blade and IR light

360° continuously pan

Uses DC brushless machine

Independent template, easy to maintenance

Speedy reaction

Designed for all-weather environment

High-intensity aluminum alloy material, perfect design

Built-in real-time monitor

Technical data:

Voltage: 24V AC

Power consumption: ≤50W

Pan speed: 1 to 60°/s

Tilt speed: 1 to 40°/s

Pan scale: 360° continuous pan

Tilt scale: -80 to 60°

Presets number: 128

Preset capture time: ≤3S

Scanning accuracy: 0.3°

Grouping tour: 4 groups 20 presets can be added to per group

Communication format: RS-485

Built-in protocol: Pelco-P or Pelco-D

Baud rate: 1,200, 2,400, 4,800 and 9,600bps

Address scale: 0 to 255

Working temperatures: -30 to 55°C

Infrared ray wavelength: 850nm

Infrared ray half-power angle: 30°

Infrared ray output power: 5,000mW

Infrared ray useful lifespan: 10,000 hours

Useful illumination distance: ≥120m

Weight: 15kg
