Tripod turnstile security gate, tripod gate barrier, waist height turnstile with competitive cost and easy to use

Tripod turnstile gate barrier JDGD-8 offers an elegant and compact crowd control solution at entrance with high pedestrian traffic flow for any locations requiring effective crowd management such as athletic facilities, cafeterias, amusement parks, stadiums, office buildings, providing smooth, precise, quiet, controller, fast arm rotation by using advance digital positioning technology. Tripod barrier gate JDGD-8 is simplified integration to access control and visitor management systems such as facial reconition, barcod, fingerprint and QR scanner.

In addition, tripod turnstile gate barrier JDGD-8 provides single directional or bi-directional access according to actual requirements. The passage will be relased upon the reception of a valid credential signal, and lock the passage immediately after the passing completed or after the predetermined time. Upon loss of power or fire system input, the horizontal arm automatically drops to provide a clear exit passageway.

Tripod Turnstile Gate Barrier Features

1. Integration possible with virtually any access solution

2. Field configurable for single direction or bi-directional operation

3. Regulates the flow of people with ease, even during the busiest periods of the day

4. Safe, controlled rotation and self-centering arm rotation

5. Free egress in emergencies or loss of power

6. The passing time can be freely set, and it will be locked immediately after the predetermined time.

7. Easy installation on finished floor surfaces, optional on unfinished surfaces

8. Extremely versatile operational features

9. functional, quick and space-saving

10.Easy, safe and fast to use

Tripod Turnstile Gate Barrier Applications

Athletic facilities

Cafeterias

Amusement parks

Stadiums

Office buildings

Residential area

Fitness center

Tripod Turnstile Gate Barrier Parameters

Housing Material : 304 stainless sheet

Dimension: 1200 x 280 x 980 mm

Power Supply: AC220V / AC110V, 50/ 60 Hz

Channel Width: 550mm

Arm Turning Angle: 120°

Pass Speed: 35 persons per minute

Input signal optional: Dry contact signal or +12V level signal or DC12V pulse signal

Rotating Direction: Bi-directional

Arm drop when power failure: Yes

Open Time: 0.2 second

Life Cycle: 5 million times

Working Temperature: -30°C~+70°C

Working Environments: Indoor, outdoor

Package : export standard carton
