Features:

"◈4 frequencies selectable for long distance and stacking installation

◈Double-precision digital display signal strength

◈Interruption time adjustable, user can adjust it according to environment and scenes

◈Intelligent heating function, effectively eliminate ice and frost, adapt to harsh environment

◈Progressively infrared signal processing functions (comparable with AGC function) to ensure the item work in wind,frost,snow,fog,moisture,direct sunlight and other bad weather etc.

◈Digital CPU control circuit to control the transmitter and receiver

◈Optional assisting equipment for alignment infrared beam, improving the efficiency

◈Wide range voltage design, power supply between AC/DC12-24V,easy for centralized power supply.

◈A variety of applications C relay outputs

◈Tamper switch, open if the cover is removed

◈Waterproof grade: IP65

◈Alignment angle horizontally ±90°，vertically ±10°"

Paramters:

Model ABT-40 ABT-60 ABT-80 ABT-100

Detection Range Outdoor 40m 60m 80m 100m

Indoor 120m 180m 240m 300m

Maximum Arrival Distance 250m 350m 500m 600m

Detection Method Simultaneous interruption of 2 infrared beams

Interruption Time 50ms,100ms,300ms,700ms (selectable)

Frequencies 4 different channels selectable

Power Supply DC/AC 12~24V

Current Consumption 70mA max 75mA max 80mA max 85mA max

Alarm Period ≥1.5sec

Alarm Output 1C. relay output (AC/DC30V, 1.0A max)

Tamper Switch NC, opens when cover removed

Protection Degree IP65

Operating Temperature     -25℃ to +55℃

Environment Humidity 95% max

Alignment Angle Horizontal 180°(±90°), Vertical 20°(±10°)

Mounting Outdoor or indoor, Wall or Pole

Material PC engineering plastic

Dimension (L*W*H) 212*80*75mm

Weight (Transimtter and Receiver) 1200g

Attachments U bracket 2pcs, 70.4*37.5*21.5mm, δ=1.5mm, stainless steel

Pole mounting srew 4pcs, PM4*30mm

Wall mounting screw 4pcs, PM4*25mm

Expansion pipe 4pcs, Φ7*27mm, green

Installation paper 2pcs, W85*H220mm

"Heaters

(additional purchase)" Voltage 12V

Current 200mA max

Temperature +70℃
