The Vega is a revolutionary multi-sensor PTZ camera boasting a long-range 135X visible day/night camera, long-range HD thermal infrared zoom, and optional ZLID NIR illumination with LRF. This multi-sensor payload enables the Vega to provide high resolution imaging in virtually any environment from heavy fog to complete darkness. Designed for accurate positioning of weapons

systems, the pan/tilt unit meets and exceeds MIL-STD-810F military ratings for shock, vibration, temperature and dust/water ingression. This makes the Vega

the ultimate long-range camera system for 24/7 situational awareness and long-range recognition and identification of targets.

Key Features:

›› Ultra Long-Range Military Grade Multi-Sensor PTZ Surveillance System

›› Day/Night 1080p HD IP ONVIF 1/2.8" CMOS Sensor

›› 15.4–1037.5mm HD IR-Corrected Zoom Lens with Motorized HD IR Doubler

›› 20°–0.15° Horizontal Field Of View Results in a 135X Zoom Range

›› Autofocus, Motorized Fog/Parasitic Light Filter & Temperature Calibration

›› Image Enhancements: WDR, HLC, EIS, 3DNR, Fog/Haze Reduction

›› 1280×1024 10μm, 30Hz Real-Time X-Hot Cooled Thermal

›› 10μm Pixel Pitch Provides 50% longer range than 15μm

›› 115–1200mm ƒ4.0 Zoom IR Lens (6.4–0.61° HFOV)

›› 20,000+ Hour Lifetime Cyrogenic Cooler

›› Up to 30km of Human Detection and 55km of Vehicle

›› MIL-STD-810F, -50°–+65°C and IP66/67

›› Elliptical Synchronous Drive, Gyro-Stabilized

›› Endless 360° Rotation Pan/Tilt from 0.001–110°/s

››0.00036° Resolution with Zero Backlash

›› 1535nm 23km Rated LRF with 50~250mm Range Accuracy

X-Hot Cooled Thermal Core

The cooled thermal camera is equipped with Infiniti''''s new

X-Hot MWIR thermal sensor, enabling 24/7 imaging that relies

on heat to allow it to see in complete darkness as well as through

smoke and light fog. The X-Hot is revolutionary technology that is

based on a superlattice design which runs at significantly higher

temperatures than InSb and MCT, greatly reducing the workload

of the cryo cooler. This extends cooler lifetime and minimizes

required maintenance. A core sensitivity of 0.025°C, as well as

its advanced DICE (Dynamic Image Contrast Enhancement)

processing, defective pixel replacement, gaussian noise reduction

filter, and automatic gain control (AGC) come together to create

an optimized image with maximum clarity and contrast
