*Supports Modbus RTU/ASCII master and slave

*Max. TCP connections (masters) per serial port: 32 (tGW-71x), 16 (tGW-72x) or 10 (tGW-73x)

*Read-cache ensures faster Modbus TCP/UDP response

*Supports UDP responder for device discovery (UDP Search)

*Static IP or DHCP network configuration

*Easy firmware update via the Ethernet (BOOTP, TFTP)

*Tiny Web server for configuration (HTTP)

*Contains a 32-bit MCU that efficiently handles network traffic

*10/100 Base-TX Ethernet, RJ-45 x 1 (Auto-negotiating, auto MDI/MDIX, LED *Indicators)

*Includes redundant power inputs: PoE (IEEE 802.3af, Class 1) and DC jack

*Allows automatic RS-485 direction control

*3000 VDC Isolation and +/-4 kV ESD protection for i versions

*Male DB-9 or terminal block connector for easy wiring

*Tiny form-factor and low power consumption

*RoHS compliant & no Halogen

*Cost-effective Modbus gateway
