* Maximum Resolution of 1920 x 1080 Pixels with the Exmor CMOS Sensor

* High Frame Rate of 60 Frames Per Second (fps)

* Scene Analytics Enhanced by Unique Features Such as Face Detection

* H.264 (High/Main/Baseline Profile)/ M-JPEG Video Codec

* Supports WDR Enhancement in Extremely Bright and Dark Environments

* External Vari-focal Lens Adjustment

* Support Intelligent Functions

* 3D+2D Digital Noise Reduction

* Power over Ethernet Available

* IR LED Built in 30M Available

* Mechanism IR Cut Filter Available

* Micro SD Card Backup(option)

* IP66

* Support iPhone/iPad/Android

* SDK for Software Integration

* Free Bundle 36 Ch Recording Software

Hardware

CPU

Multimedia SoC

RAM

256MB

Flash

512MB

Image Sensor

1/2.8” Sony Exmor CMOS Sensor

Sensitivity

Color : 0.01 Lux (AGC ON)

B / W: 0.005 Lux (AGC ON)

Lens Type

Vari-focus Lens 3~10.5mm @ F1.4

Angle of View

31.9 ~ 104.9° (H)

17.2 ~ 53.9° (V)

ICR

Mechanism IR cut Filter

LED

Built-in 35 IR LED

IR Distance-30M

I/O

1 DI/ 1 DO

Video Output

Yes

Audio

G.711(64K) and G.726(32K,24K) audio compression

Input : 3.5mm phone jack, audio in

Output: 3.5mm phone jack, Support 2-way.

Power over Ethernet

Yes

Power Consumption

DC12V Max: 6W(IR ON), 3.72W(IR OFF)

PoE Max: 7.2W(IR ON), 4.5W(IR OFF)

Operation temperature

-10℃ ~ 50℃

Dimensions

83mm (Æ) x 180mm (H)

Weight

1350g

Network

Ethernet

10/ 100 Base-T

Network Protocol

IPv6, IPv4, HTTP, HTTPS, SNMP, QoS/DSCP, Access list, IEEE 802.1X, RTSP, TCP/ IP, UDP, SMTP, FTP, PPPoE, DHCP, DDNS, NTP, UPnP, 3GPP, SAMBA, Bonjour

Wireless (Optional)





Wireless

802.11b/g/n

Security

WEP,WPA-PSK,WPA2-PSK

System

Video Resolution

1920x1080@60fps, 1280x720@60fps, 640x480@60fps, 320x240@60fps, 176x144@60fps

Video Adjust

Brightness, Contrast, Hue, Saturation, Sharpness, AGC, Shutter Time, WDR, Flip, Mirror, Day&Night adjustable, White Balance, Denoise

Triple Streaming

Yes

Image Snapshot

Yes

Full Screen Monitoring

Yes

Privacy Mask

Yes, 3 different areas

Compression Format

H.264/ M-JPEG

Video Bitrates Adjust

CBR, VBR

Motion Detection

Yes, 3 different areas

Triggered Action

Mail, FTP, Save to SD card, DO, Samba

Pre/ Post Alarm

Yes, configurable

Security

Password protection, IP address filtering, HTTPS encrypted data transmission, 802.1X port-based authentication for network protection

Firmware Upgrade

HTTP mode, can be upgraded remotely

Simultaneous Connection

Up to 10

SD card management (option)

Recording Trigger

Motion Detection, IP check, Network break down (wire only), Schedule, DI

Video Format

AVI, JPEG

Video Playback

Yes

Delete Files

Yes

Client System requirement

OS

Windows 7, 2000, XP, 2003, Microsoft IE 6.0 or above, Chrome, Safari, Firefox

Mobile Support

iOS 4.3 or above, Android 1.6 or above.

Hardware Suggested

Intel Dual Core 2.8G,RAM: 4GB
