• 16 Duty Timetable.

• 32 sets siren output.

• Memory full warning.

• Suitable for chains and enterprises.

• Built-in TCP/IP communication interface to PC.

• Watchdog function ensures device free from halting.

• At least 60 days data storage in case of power outage.

• Cope with seasonal time change - daylight saving control.

• Simple, reliable & easily installed, first time set up in 3 minutes.

• Follows your usual practice - auto or manual clock in / clock out.

• Invalid & re-swiped cards off-the-record saves memory capacity.

• Auto scheduling for data collection, time synchronization, valid card download.

• RTC (Real Time Clock) ensures accurate time regardless of power outage.

• Dynamic control of memory up to 8000 cardholders (max), 8200 transaction data.

• Visual LED for display of time, card number, communication mode, swiped card indication.

• PoE (Power Over Ethernet) for HTA-840, eliminates serial cable material & installation, power adapter - significant cost saving.

Specifications：

Model No.

HTA-830

HTA-840

Cardholders/Events

8,000 / 8,200

Keypad

Duty switch by A, B, C, D

Output Ports

1 Relay (Siren / Door Lock)

LED Indicator

Visual LED for display of time, Swiped card indication (last 4 digits), Comm. x 1

Real Time Clock

Yes

Beep Tone

Buzzer

IP Setting

Software

Read Format & Range

ABA-Track2 / Wiegand x 1

● EM

RF 125 KHz, 8~10cm (max.)

● Mifare®

RF 13.56 MHz, 5cm (max.)

Power Input

DC 12V / 1A

Power PoE HUB

Power Consumption

500A (max.)

Comm. Interface

TCP/IP

TCP/IP (PoE)

Comm. Baudrate

10/100 Mbps

Operating Temp.

-10° C ~ 55° C / 14° F ~ 131° F

Relative Humidity

20% ~ 80%(Non-condensing)

Dimension

160mm(L) x 100mm (W) x 40mm (H) (excluding base)

Weight (Device)

400g
