• May connect 8 T2/Wiegand or RS-485 readers for door controlled.

• Support standard Wiegand 26 interface reader and up to Wiegand 72 interface.

• Support 2 ~ 4 door interlock function.

• Provide 2 relay outputs for electronic lock and alarm.

• Support various alarm functions, like door is not closed, forced open door and reader broken.

• Provide 2,000 hardware events.

• Provide 256 time zones & schedules , each time zones.

• 8 time conditional unlock door schedules per door, provide flexible management.

• 100 holiday schedules per year.

• Three entry modes: card, card with password, input card number.

• Support card number with English alphabet, max. 14 characters.

• Request to swipe first card to activate door relay when in the unlock door time schedule.

• Allows to open door by any card before upload authorization (Default). Operator  can disable this function and set not to open.

• Support Blacklist , Patrol Card so on , also can set up cards valid date ,increase the safety of Access Control.

• Anti-passback and Duress card/code setting. When door opened in the emergency, controller will send signal to control center at the same time for tracing and rescue.

• TCP/IP communication interface to PC.

• Able emote open or close door by software.
