• May connect 4 T2/Wiegand or RS-485 readers for door controlled.

• Provide 15,000 authorizations

• Provide 37,000 swipe card records

• Provide 1,000 hardware events.

• Duress card/code setting. When door opened in the emergency, control panel will send signal to control center at the same time for tracing and rescue.

• Provide 128 time zones and schedules

• 8 time conditional unlock door schedules per door, provide flexible management.

• Provide holiday schedules to current and next year. 100 sets per year.

• Three entry modes: card, card with password, input card number.

• Support card number with English alphabet, max. 13 characters.

• Blacklist to prevent unknown usage of lost card.

• Anti-Pass back function

• Able remote open or close door by software.

• Support interlock function

• Support various alarm functions, like door is not closed, forced open door and reader broken.

• Authorizations and swipe card records may save in the panel over 10 years after power off.

• Strengthen electromagnetic compatibility design, it compatibility with Surge test and EFT of EN55024.

• TCP/IP interface may connect with HAMS for access control management.

• Support passive and active TCP/IP communication.

Input Ports

8 sensors

(Door Sensor x 2、Exit Button x 2、 Case Sensor x 4)

Output Ports

4 Relay (Door Lock x 2、Alarm x 2)

Cardholders

15,000

Swipe Card Record

37,000

Hardware Event

1,000

LED Display

Power / Output Status / Comm.

Real Time Clock

Yes

ID Setting

IP tool setting

Reader Port

T2 / Wiegand x 4 or RS-485 X 1

Power Input

DC 12V / 1A (excluding slave reader)

Current Consumption

500mA (max. excluding slave reader)

Comm. Interface

TCP/IP

Comm. Baudrate

10/100 Mbps

Operating Temp.

-40˚C ~ 70˚C / -40˚F ~ 158˚F

Relative Humidity

20% ~ 80%(Non-condensing)

Dimension

150mm(L) x 210mm(W) x 29mm(H)
