Detection Day: 3km;

　 Night: 1.5km

Consumption 12W，808nm ,military NIR

Laser angle 0.7°～20°

Angle and distance matching 1.DSS digital stepper illumination angle control, unique laser angle and distance matching technology, min 0.1°follow-up zooming

2.GHT-II super homogenizing HD illumination technology

3.0.01°SLM optical axis aiming and locking

Camera

　 1/1.8''''CMOS

0.0002lux high sensitive color to B/W CCD

2MP, 1920*1080,Automatic ICR switch

H.264/MPEG4/MIPEG video format, support dual stream

Video Bitrate 32Kbps~16Mbps，60Hz30 frame/S

Support SD storage

Support fog penetration, avoid strong light,128dB WDR, 3D denoise, anti-shake DSP, auto back focus adjustment

Lens 18-550 mm

MOD:3M

105mm super caliber

motorized /manual zoom, DC 8~12V, auto IRIS,DC5V

Penetrate fog AFR

LPR (optional) Avoid strong light automatically, license plate recognition

Housing 1. Material: integral aluminum alloy housing，sealed and waterproof

2.Structure: double window design (wiper for option)

3.Surface spraying :PTA three-resistance coating, anti corrosion(optional)

4.Weather proof: IP66, waterproof, dustproof

5.Connector：Aviation Water-Proof Connector

PT

　 50kg

Pan: 360°continuously，Tilt: +45°～-45°

Pan: 0.01～30°/S，Tilt: 0.01～15°/S

Preset：80 (245 for option) with patrol and scan function
