Detection 10000m（2.3X2.3m object）

Visible camera CCD 1/3'''' CCD , 440000 pixel，600 TVL /2 mega pixel, HP1080P

Spectral response 0.4～1.0um visible light, NIR

Min. illumination 0.006lux

Video standard PAL(NTSC)/H.264

Color Color, B/W

Lens 3.4～122.4mm,10～210mm,12～320mm,15～500mm,30～750mm HD lens, motorized focus/zoom, auto iris

Thermal camera Sensor 336*256 or 640*512, 5th UFPA

NETD NETD 50mk（@ 25o F1.0）

Spectral response 7.5～14um

Lens 75mm,105mm,155mm,F1.1, motorized zoom

Imaging process Without TEC stable operating temperature, startup ≦4s.

SDE digital image enhancement technology to enhance image detail,

10 kinds of pseudo-color images and hot black hot white two polar images.

2X, 4X digital zoom

LRF(optional) Wave length 1.57um

Detection 50m—10000m

（max 15000m）

Ranging Accuracy 3m

Repetition frequency 10 cycles / minute

Power supply DC24V

Interface RS422 full duplex

Laser illuminator（optional） Laser Power 6W, 8W, 10W, 15W
