Detection

Vehicle: 16400m

Human: 5800m

Identification

Vehicle:4200m

Human: 1600m

Sensor 5th generation UFPA sensor

Resolution 336*256 pixel (640*512 optional)

Spectral 7.5～14μm

NETD 50mK（@25℃ F1.0）

Focal length 38～190mm

FOV(H) 9.5°～1.9°

IFOV 0.09～0.45mrad

Lens control Motorized zoom and focus(optional auto focus)

Image processing 1. Stable operational temperature without TEC, starting time less than 4 seconds

2. SDE digital image processing

3. 10 pseudo color and B/W, B/W inverse

4. AGC

5. 2X digital amplification

Housing 1.Material：High strength aluminum alloy shell，waterproof seal，To avoid the growth of mold and moisture generated

2.Structure：Integrated single-window design

3.Surface coating：PTA three-resistance coating, Seawater corrosion resistance

4.Interface：Aviation waterproof plug

PT（optional） 1. Duty: 20kg

2. Rotation: Pan: 0～355°, Tilt: -60～+10°

3. Rotation speed: Pan: 9°/S, Tilt: 4°/S，

4. Preset 32（Optional variable speed PT）

Interface 1.RS-485（PELCO D protocol, baud rate 2400bps

2.Remote OSD setting

3. PAL/NTSC video output

4. AC24V ( DC12V optional)

5. Waterproof connector

Environment 1.Operating temperature：-25℃～+55℃（-40℃ optional）

2.Storage temperature：-35℃～+75℃

3.Humidity：<90%

4.Ingress protection：IP66
