FEATURES

NETD: 50mk

Detector: VOX

Pixel size: 17um

APPLICATION

City Surveillance, Forest fire, Vehicle tracking

Target characteristic analysis, Electric Monitoring, Measuring equipment

  Technical Specification

Mode EQ3 EQ6

Array format 384x288 640X480

Pixel size 17μm

Detector VOX

Spectral range 8~14μm

NETD ≤50mk@30ºC

Boot up ≤3S

Calibration Digital Thermal Imaging NUC

Noise reduce Digital filtering

Image enhancement Digital Image Enhance

Electric zoom 2X, 4X, 8X, 16X digital zoom

Polarity reversal Available

Image Flip Option Horizontal, Vertical , 180° Flip

Frame rate 25Hz

Video output CVBS 50Hz(PAL )/ 60Hz(NTSC)

Palette 12 Palettes

Level adjustment Automatic/Manual

Brightness/Contrast Automatic/Manual

OSD Firmware programmable, Full-screen overlay

Port  RS 232

Power Available

Analog video interface BNC

Operate voltage range DC  5V

Operating temp. -40ºC~+60ºC

Storage temp. -45ºC~+85ºC

Humidity ≤95% (non-condense)

Dimension 45 x 43 x 41.5mm(L x W x T) without lens

Weight <110g(without lens)

Focus Lens 6.8, 8.5, 13, 19, 25, 35mm optional
