The HID EdgePlus IP Access Solution puts control and host interface right at the door. The EdgePlus E400 is a true IP access solution that manages up to 44,000 cardholders or credentials in complete and full-featured host systems. And an EdgePlus can be placed anywhere at the door to address all security requirements. A fully integrated processor right at the door thatˇs an ideal solution for retrofits or new installations, EdgePlus requires less wiring and uses standard CAT-5 or 6 cabling for both data and power. With a separately connected reader, EdgePlus is a perfect solution for migrating existing reader installations to the "edge" of the network. Whether the enterprise is iCLASS, Prox, FlexSmart, FlexPass, MIFARE/DESFire, CRESCENDO or Wiegand output reader, EdgePlus delivers Intelligence at the Door.

Features:
* Connects with and stores a complete access control and configuration database for one controlled door and 44,000 cardholders
* 255 configurable priorities for supervised inputs/alarms
* Compatible reader protocols includes all wiegand or HID formats up to 128 bits and iCLASS RS-232
* Incorporates the HID OPIN Technology TCP/IP API with an available Windows DLL tool * Enables IP-based, two-way communication with iCLASS reader/writer, LCD keypad and biometric reader products
* Built-in 802.3af Power over Ethernet (PoE), with 700mA available for external field devices
* Accepts local connection option via laptop for diagnostics and configuration
* Connects to host on the IP network * Controls and powers all access devices at the door
* Buffers up to 5,000 transactions if communication is disrupted with host and uploads when network communications are restored
* Controls and reports any passback (hard/soft/med)
* RS-232 serial port for optional back-up via modem
