Video Input: 16 channels video input

BNC(Vp-p = 1.0V, 75)

Audio Input: 16 channels audio input

BNC(Vp-p=2.0V,SNR > 83DB,Linear Electrical Level ,1000?)

Total Frames PAL: 200 fps / NTSC: 240 fps

Compression Algorithm Video: H.264 / Audio: G.729

Compression Resolution CIF 352*288(PAL) / 352*240(NTSC)

Preview Resolution D1 704*576(PAL) / 704*480(NTSC)

Video Compression H.264, Support CBR, VBR

Audio Compression G.729, Audio 8kbit/sec and PCM 64kbit/sec

Alarm In/Out Support

PTZ Support

Motion Detection Motion area and sensitivity adjustable

Other functions Watchdog / Dual Stream

Power Consumption Less than 22W

Working Temperature -10C+50C

Working Humidity 10%90%

Dimension 132mm⊙91mm

Weight 90g

Interface PCI

System Requirements

OS : Windows 2000/XP/Server 2003/Vista

CPU : Intel Series

Mothercard: based on Intel 845/865/915/925/945 Chipset

Memory: 512MB or above

Display Adapter: Nvidia Geforce Mx400/440/4000 series,

FX 5200/5600 GeForce 6600

ATI Radeon 9550/9600 serials,

ATI X300/X550/X700/X1600

Intel 845G/865G/915G/945G integrated Graphics Controller
