FEATURES

--Full spectrum flame detection, detection and localization of naturally burning flame body

--Speed flame detection and output

--Anti interference of various light sources

--Long detection distance

--Detection sensitivity 0-100 level adjustable

--Full screen detection

--Supports four shielding zones and four detection zones

--Can detect kerosene, diesel, gasoline, alcohol, butane, natural gas, liquefied gas, paper, fabric, wood, organic materials and other combustible flame combustion

--Support for 4 irregular shielding areas to prohibit detection in this area ;

--The detection algorithm runs on the whole front-end camera, independent of the back-end server or the cloud, and can run under the condition of network disconnection

--Alarm information can be pushed to mobile phone APP and IMS platform, and corresponding docking protocol interfaces are supported for third-party integration

SPECIFICATION

Flame detection performance

-Limit of detection

Can detect the image of no more than 10 pixels of flame, available in field configuration

-Coverage and sensitivity

In the case of indoor light intensity of 0-500lux, in the horizontal range of 70° (about 4mm corresponding focal length)

1:The flame of the common liquefied gas lighter (5cm high flame) can be detected in 10 meters or more distance and alarm;

2:For standard 2cm fire pan (gasoline and kerosene half) flame, can be detected from 25 meters away and alarm

-Response Time

From the appearance of the flame, the maximum detection time is not more than 10 seconds, and can be increased to less than 1 second in a specific environment through the configuration of manual interface parameters.

-Anti-interference

Under the normal downward view installation mode, there will be no false positives due to various neon lights 2 meters away, the flame scene played by the player, the flashing light, the reflected light from the ground, the mobile phone filling light, etc.

-Subject range

Full spectrum flame detection: can detect all kinds of flame, typical combustion caused by combustion, including but not limited to kerosene, diesel, gasoline, alcohol, butane, natural gas, liquefied gas, paper, fabric, wood, organic materials and other combustible flame
