FEATURES

8CH full real-time network video access,1U NVR case

H.265,H.264 dual-stream decoding,embedded Linux operation system

Support sync video recording,remote monitoring,backup

Support VGA/HDMI sync output,2160P HD preview

Support amplification preview and playback video image

Standard ONVIF,RTSP,GB28181 protocol

Support external alarm,bidirection talk,alarm snapshot,email sending functions

Support 4 standard POE power supply

Support DDNS,EMAIL,UPNP,NTP,P2P,etc,and WEB,mobile viewer,Client,CMS monitoring

Support IPC intelligent functions(target counting,items left/lost,electronic fence,crossing detection,retrograde detection,departure detection)

Support grouping disk quota,and disk inventory two storage pattern,distribute different video storage capacity/cycle according to different channels

Support IPC centralized management,including IPC parameters configuration,import and export information ,information real time acquisition,etc

Support channel grouping,preview round touring.And dual password authentication IP filter

Support network detection(network flow monitoring,network wireshark,network clear)function,etc

Support max 8CH sub stream sync playback and multi-channel sync play backward

Support instant playback

The new UI interface,support a key to open the video recording

Product parameters

VIDEO

8CH Network video input

40Mbps Network access bandwidth

Video output

1CH VGA output(1920×1080@60HZ,1280×1024@60HZ)

1CH HDMI output(1920×1080@60HZ,1280×1024@60HZ)

Display mode

Synchronous output

System mode

8 digits+9 preview+4 playback

Video bit rate

16-8000Kbps

Video resolution

5/4/3MP

1080P/960P/720P

D1/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Image display

1/4/6/8/9 image display

Snapshot mode

timing snapshot

manual snapshot

JPEG format

Motion detection

396(22*18)surveyed area can be set in every screen and multi-level sensitivity adjustable

Privacy mask

4 zones

AUDIO

Audio compression

G.711u

Audio input

1CH RCA port

IPC complex audio input

VIDEO RECORDING AND PLAYBACK

Video frame rate

1-30fps

Record mode

manual

Timing+alarm record

Timing record

alarm record

Stop record

Playback ability

4CH sub stream sync playback

Playback mode

Instant playback

local record

Playback snapshot

external file playback

Record search

Time,calendar,channel search,event search

ANR,regular video,motion detection video,alarm video,intelligent detection video

STORAGE AND BACKUP

Storage interface

1*SATA

HDD capacity

Single max.8TB

Backup location

Local

network

Backup method

USB mobile hard disk

U disk

network backup

ANR

FSAN IPC(with TF card)
