FEATURES

-Use the built-in deep learning algorithm of human shape and car shape,suitable for traffic statistics

-Only human or vehicle detection and analysis,other moving objects will not be affected by detection

-Support target counting,electronic fence,retrograde detection,off-site detection

-Support to calculate the statistics of import and export persons and vehicle flow

-Support 3D digital noise reduction and TWDR

-Support automatic electronic shutter function,adapt to different monitoring environment

-Support a variety of intelligent alarm linkage output

-Change the password when starting the initial equipment to ensure the security of the password,PoE power supply

SPECIFICATION

CAMERA

-Image sensor

1/2.8"SONY 2 Mega Progressive Scan Exmor CMOS

-Min.illumination

0Lux/F1.4(IR ON)

Color: 0.02Lux/F1.4

B/W:0.002Lux/F1.4

-IR Distance

20-30M

30*Φ5 red lights

-Electronic shutter

Auto

Manual(1/5~1/100000)

-Day/Night

ICR switch

auto

color

B/W

ext

-Lens

2.8/3.6mm lens

-Lens interface

Φ14

-S/N ratio

≥50db(AGC OFF)

-Output

PAL

NTSC

-Adjustable

WDR

Light board control

3D N/R

Defog

Mirror

Slow Shutter

Exposure control

-Image setting

Brightness

Contrast

Saturation

Sharpness

Hue

AUDIO/VIDEO COMPRESSION

-Encoding features

NTSC:main stream:1920X1080@30fps

sub-stream:D1@30fps

PAL:main stream:1920X1080@25fpss

sub-stream: D1@25fps

-Third stream

NTSC/PAL:1920x1080@10fps

-Max.Resolution

1920X1080

-Video bit rate

Constant

variable(16kbps~8000kbps)

-Video type

Complex

Video

-Audio control

Input/output volume gain control

-ROI

4 zones,multi-stage level

NETWORK

-Access protocol

GB28181

-8 Video preview meanwhile

-User permission

User add/modify/delete

permission management

-Safe mode

Authorized user name and password

HTTPS encryption and AES link encryption

RTSP verification

-Motion detection

Set detection zone

Multi-level sensitivity can be set

-Intelligent analysis

Detection and analysis of the behavior of persons or vehicle targets only

-Multicast function

-Device exception detection

Network disconnected

IP conflict

illegal access alarm

Human and vehicle shape detection

-Target Counting

-Electronic Fence

[SAME Retrograde Detection]

Detection type:target entry,exit,wander,or intrusion detection

-Retrograde Detection

Setup time can be set

Test line can be set up,up to 4

-Off-site Detection

[SAME Retrograde Detection]

Departure time is available

-Report statistics (valid with TF card)

Target count:daily/monthly reports, line charts, bar charts, lists

Electronic fencing: lists

Retrograde detection: list

Departure detection: list
