-Effective picture elements 2.1M Pixels

-Optical 18x

-Auto Focus Lensf=4.7~84.6ｍｍ　F1.6(W)~F2.8(T)

-Digital zoom 12x (216x with optical zoom)

-Angle of view (Horizontal x Vertical) 55.2°(wide) to 3.2°(tele)Aspect(HD)16:9 (SD)4:3

-Image signal HD: 1080/60p,50p,30p,25p,24p,60i,50i,30i,25i 720/60p,50p,30p,25p(59.94/24.97/23.97p available)SD: TV composite

-WDR 80dB

-White Balance Auto/ATW/Indoor/Outdoor/One push/Manual

- Synchronization Internal AE Control Auto / Manual / Outdoor / Shut-P / Iris-P / Spot AE

- ICR Auto/ Manual

- Minimum illumination 0.05lux (Mono 1/2sec at Gain32dB )

S/N ratio 56dB

- Power input （Option）DVI (TV composite), 1.5G /3G -SDI (TV composite)

- Slow shutter 2sec-1/10,000sec

- Gain +32dB

- Gamma 0.3, 0.45, 0.6, 0.8, 1.0 (4step)

- Edge Enhancement16 steps

- Operating Temperature/Consumption 0 -45 degree?/5W

- Max consumption current Max 600mA(DC12V)

- Privacy masking 8 point

- Mirror reverse imageYes

- Picture effects Nega art / Black and White/Picture freeze

- Control VISCA/PELCO-D
