• 30X optic zoom, 12X digital zoom

• Support auto-iris, auto-focus,AWB,BLC,WDR

• Lens F=4.3mm-129mm

• Support min. Illumination, 0.02Lux/F1.6(color),

0.002Lux/F1.6(black & white )

0 Lux with IR

• Resolution 1080p/30,1080p/25,720P/30

720p/25, 720p/60, 720p/50

IR Characteristics:

• Min. Illumination 0Lux

• Using high effective array lamps, low power consumption, Infrared range will be over 150m

• Infrared lamp & ratio distance matching algorithm, is based on distance & ratio to adjust brightness and angle of this lamp,making the image to achieve the ideal state.

• Built-in heat treatment device, which can reduce the temp of dome to avoid being fog

• Constant current circuit design, infrared lamp life 30,000 hours

PTZ Characteristics:

• Using high quality CMOS sensor, image resolution, support max. 1920X1080@30fps

• Precise motor drive, sensitive reaction, smooth running, precision error less than 0.1 degree,no image shaking under any speed

• Support PAL/NTSC, which can be suitable for most of areas

• Support RS485 remote control

• Support OSD menu & operating reminders, clear user interface, easy to operate

• Support power-off memory, PTZ & Lens can return former state after power-on again.

• Support IP66 weather protection grade

• Pan 360°continuous rotation, tilt(+90°90°) no dead-angle, auto-flip

• Horizontal speed: 0.1° -200°/s,Vertical speed:0.1° -150°/s

• Support 128 presets, 4 scanning tracks, 1 self-learning track

• Support 6 programmable tracks, for each track, max. 16 presets added

• Support ZAP function, rotation speed can be automatically adjusted as lens zoom

• Support idle functions,preset/figure/programmable/automatic scanning, can automatically call in a specified time of idle state(including a idle state after power on)

• Support alarm function, 7x in, 2x out (optional)

Networks Characteristics:

• Support H.264/MJPEG compression,dual-stream,high compression ratio & video quality

• Support dual-stream, main stream 1920X1080

• Support module AWC/ATW, AGC,BLC,brightness,color, saturation and contrast, sharpness,etc.

• Percentage zoom limit speed function: Manual controlling speed of has a percentage with the depth of lens focus, make sure to search the aims steady.

• The title of IP dome camera, time, stream information, angle, zoom, etc., will be displayed

• Support ONVIF2.3 and GBT28181

• Support protocols , such as TCP/IP,UDP,RTSP, etc

• Support motion detecting, network failure detection,etc., and alarm in , image capture

• Support remote control, cellphone client software

• Support Ethernet control, analog output (CVBS) and RS485 is optional
