Network Interface

Ethernet 10/100Base-T (RJ-45)

Network Protocol

TCP/IP，HTTP，NTP，IGMP，DHCP，UDP，SMTP，RTP，RTSP，ARP，DDNS，DNS，P2P

Compatibility

Support Hikvision,XM,TOPSEE etc center platform management software

Interface Protocol

ONVIF2.4/GB28181(Option- Customize)

Mobile monitoring

Operating System

Android/IOS

Camera

Image Sensor

1/2.8” 2.0M piexls Sony IMX327 CMOS

Optical Zoom

18X

Minimum Illumination

Color: 0.03Lux at F1.5; B/W: 0.001Lux at F1.5; 0Lux(IR on)

WDR

More than 100dB

S/N Ratio

More than 48dB(AGC off)

Day/Night

Auto(ICR) / Color / B/W

Angle of View

72° ~ 3.8°

Electronic Shutter Speed

1/2 - 1/20,000s

Noise Reduction

DNR,3DNR

Defog

Support

Max. Aperture

F1.5~F2.7

White Balance

Auto, ATW, Indoor, Outdoor, Manual

Gain Control

Auto / Manual

Video

Compression

H.265/H.264/MJPEG

Video Interface

1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC (S/N ratio≥ 55dB)

Resolution

Main stream:1920x1080,1280x960,1280×720,720×576,640×480

Sub stream:640×480,352×288,320×240,176×144

MJPEG:1920x1080,1280×720

Max Frame Rate

H.265/H.264: 30fps@1920x1080

Bitrate

MainStream:10.0Mbps@VBR/Sub Stream:32Kbps@VBR

Audio

Algorithm

G711,PCM

Input

1 x Line-In (Mini-stereo, Single Mono)

Output

1 x Line-Out (Mini-stereo, Single Mono)

Pan/Tilt

Range

Pan : 360°(Endless)/ Tilt: -10~90°

Pan/Tilt Speed

Preset Max.:131°/sec

Manual : 0.1° ~ 131°/sec (Zoom Proportional)

Patrol : 1.4°~131° /sec

Preset

246Presets and 9 presets for special function

Patrol Scan

3 Group Patrol

Air Wiper

Auto / Manual

Other Functions

Auto Flip, Auto Parking, Power-up Action & etc

Alarm

Alarm Input

1(ON/OFF signal)

Alarm Output

1(ON/OFF signal)

Infrared

IR distance

150m-200m(Max.)

Wave

850nm

Physical

IP protection

With IP66

Operating Temperature

–35℃~60℃

Humidity

0%~98% (Non condensing)

WIFI/4G Module

Extend WIFI /4G module(Option- Customize)

Store

TF Card

Power Source

AC24V 3A 60Hz/50Hz

Power Consumption

AC24V：8W-47WNetwork
