Standards

• Cellular Frequency Bands: (Please see order information for optional band)

• 4G LTE: FDD-LTE, TDD-LTE, Transfer rate (max):

LTE FDD: 150Mbps down; 50Mbps up/LTE TDD: 130Mbps down; 35Mbps up

• 3G: WCDMA, Transfer rate (max): 42Mbps down; 5.76Mbps up

• 2G: GSM/EDGE, Edge Transfer rate (max): 236.8Kbps down & up

Antenna connector

• 2 x SMA Male

SIM Slot

• 2

WLAN Interface

WiFi

• 802.11 a/b/g/n/ac 2T2R (2.4G/5GHz selectable)

Frequency Band

• Europe CE/2.4 GHz (13 channels) 5GHz (4 channels)

• America/FCC 2.4GHz (11 channels) 5GHz (9 channels)

• Taiwan NCC/2.4GHz (11 channels) 5GHz (9 channels)

• Singapore iDA/2.4GHz (13 channels) 5GHz (9 channels)

• JAPAN TELEC & JATE/2.4GHz (13 channels) 5GHz (19 channels)

Encryption Security

• WEP, WPA 1/2-PAK & WPA 1/2 (8 x VAP/SSID)

Antenna connector

• 2 x SMA Female

Ethernet

Standards

• IEEE 802.3 10Base-T

• IEEE 802.3u 100BASE-TX/100BASE-FX

• IEEE 802.3ab 1000BASE-T

• IEEE 802.1x, Full duplex flow control

Ports

• 1 x RJ45 GE (WAN/LAN configurable) +4 x RJ45 GE

Physical Layer

• 10/100/1000Base-T

Serial

Ports

• 1 x RS232/RS485

I/O

DI/DO

• 1 x Digital In (“Logic 0”: 0-2V, “Logic 1”: 5V-30V), 1 x Digital Out (Relay Mode, up to 30V/1A)

USB

Standards

• USB 2.0

Ports

• 1 x USB Type A

Functions

WiFi LAN

• AP Router, WDS, WDS Hybrid Modes

VLAN

• Port-based, Tag-based VLAN

Port Forwarding

• Virtual Server/Computer, DMZ Host, PPTP/L2TP/IPSec Pass-through

Routing

• Static, Dynamic: RIP1/RIP2, OSPF, BGP

QoS

• Policy-based Bandwidth Control and Packet Flow Prioritization

Virtual COM

• RFC2217, TCP Client, TCP Server, UDP

Modbus

• Modbus Slave; Modbus Gateway for Modbus TCP, Modbus RTU/ASCII Master/Slave Access

VPN

• IPSec, OpenVPN, PPTP, L2TP, GRE

Firewall

• SPI Firewall with Stealth Mode, IPS

Event Engine/Event Handling

• Managing/Notifying Events: DI, DO, Modbus, SMS, Syslog, SNMP Trap, Email Alert, Reboot

Device Management Solution

• eVue (Q4, 2018)

Power

Input

• DC 12V-48V (Terminal Block)

Power Consumption

• 25W Max.

Mechanical

Dimension

• 62 x 135 x 160mm (with DIN Rail kit)

Weight

• 1.2Kg (2.64lb)

Installation

• DIN-Rail

Environment

Operating Temperature

• -30 to 70°C (-22 to 158°F)

Storage Temperature

• -40 to 85°C (-40 to 185°F)

Ambient Relative Humidity

• 5% to 95% (non-condensing)

Regulatory Approvals

Safety

EN 60950-1

EN 62368-1: 2014

Emissions/Immunity

CE/NCC BSMI
