Technology

Standards

• IEEE 802.3 10BASE-T

• IEEE 802.3u 100BASE-TX/100BASE-FX

• IEEE 802.3ab 1000BASE-T

• IEEE 802.3z 1000BASE-SX/1000BASE-LX

• IEEE 802.3x Full duplex and flow control

• IEEE 802.1p QoS

• IEEE 802.1Q Tag VLANs

• IEEE 802.1s MSTP

• IEEE 802.1w RSTP

• IEEE 802.1x Port-based Network Access Control

• IEEE 802.1ab LLDP

• IEEE 802.3ad LACP

• IEEE 802.3at Power over Ethernet

• IEEE 802.3az EEE Energy Efficient Ethernet

Forward and Filtering Rate

• 14,880pps for 10Mbps

• 148,810pps for 100Mbps

• 1,488,100pps for 1000Mbps

Power Input

• 100 to 240VAC, 50/60Hz

Power Consumption

• Device: Max. 25W (without PoE)

• PoE power budget: 370W

PoE Power Output

• IEEE 802.3at: up to 30W/port, 50VDC, 600mA

Mechanical

Casing

• Metal Case

Dimensions

• 442 x 211 x 44mm (W x D x H)

(17.4”x 8.3”x 1.7”)

• Standard 19” rack-mount size, one-unit-height

Weight

• 3.3Kg (7.26lbs.)

Installation

• Rack mounting

Interface

Ethernet Port

• 10/100/1000BASE-T: 24 ports

• 100/1000 SFP: 2 ports

LED Indicators

• Per Unit: System

• Per Port: Link/ACT/Speed, PoE

Environment

Operating Temperature

• 0 to 45°C (32 to 113°F)

Storage Temperature

• -20 to 70°C (-4 to 158°F)

Ambient Relative Humidity

• 10% to 90% (non-condensing)

Regulatory Approvals

ISO

• Manufactured in an ISO 9001 facility

Safety

UL 60950

EMI

CE Mark Class A

FCC Part 15 Class A

VCCI Class A
