·36 pieces IR-LED

·Illuminate distance >30m

·IP66 Weatherproof

Model No. EST-AHD6452 EST-AHD64513 EST-AHD6451

Effective Pixels 2.0 Mega Pixels 1.3 Megapixels 1.0 Mega Pixels

Image Sensor 1/2.8" SONY Exmor CMOS Sensor 1/3" SONY Exmor CMOS Sensor 1/4" Aptina CMOS Sensor

DSP Nextchip 2431H Nextchip 2431H Nextchip 2431H

Min. Illumination Color 0.01Lux@F1.2 Color 0.01Lux@F1.2 Color 0.01Lux@F1.2

B/W 0.001 Lux@F1.2 B/W 0.001 Lux@F1.2 B/W 0.01 Lux@F1.2

Signal System PAL/NTSC or CVBS/AHD

On Screen Display Yes Yes Option

OSD Function：Manual/DC Lens,Shutter/AGC/WB,Pict Adjust,Mirror,Day/Night,DNR,BLC/HLC,Motion Detect,Privacy Zone

IR Cut Filter ：IR LED synchronous switching double filter

Lens Mount：Board Lens 3.6mm

Infrared Luminary：36 pieces IR-LEDs

Infrared Wavelength：850 nm

Illuminate Distance：More than 25 M

Waterproof Criterion：IP 55

I/O Connector：1*DC Power Connector ,1* BNC Video Connector

Supplied Voltage：DC12V

Power Consumption：IR On: 600mA max., IR Off: Less than 200mA

Working Enviroment：-10°C~+60°C, 10%~90% ( Built in Heater being optional added for enviroment lower than -20° )

Dimensions：200*100*85mm

Weight：0.5 kg
