The ENFORCER illuminated Indoor Stand-Alone Keypad now features a built-in proximity card reader for greater security than the previous SK-1131-SQ. The 4 programmable access modes allow you to choose your level of security to require either a Card alone, a User Code alone, a Card and Common User Code, or Card and Unique User Code. The SK-1131-SPQ is highly customizable for your needs.


• Built-in proximity reader. 125kHz(EM125)
• 4 Available programmable access modes for all 3 outputs: card only, code only, card and common user code, card and unique user code
• 1,200 Users over 3 Outputs. Codes may be 4~8 digits:
- Output #1 – Form C relay, 1A@30VDC, 1,000 users
- Output #2 – Form C relay, 1A@30VDC, 100 users
- Output #3 – Transistor ground, 100mA@24VDC, 100 users
• Super user code gives admin access to keypad
• Durable and attractive stainless steel faceplate
• Programmable lock out or duress output after 5~10 unsuccessful attempts to key in a code
• Relay output inhibit control
• Programmable egress input with optional warning alarm and delayed egress
• Built-in tamper (N.C.) circuit
• EEPROM memory prevents data loss
• Power: 12~24 VAC/VDC
• Illuminated keypad with programmable status LEDs
• Door-propped-open warning
• Alarm output triggers an optional alarm control panel if a protected door is forced open
• Optional door open alarm
• Mantrap: for a protected area with two doors, this feature allows only one door to be open at a time
• Duress output signals a silent alarm if an authorized user is forced to open the door under duress
• Keypad active output activates for 10 seconds when any key on the keypad is pressed
• Visitor codes can be programmed for one time use or for a specific amount of time
• Real-time clock to auto-disable access at specific times
