With on-screen display for customized setup

The OSD function enables the adjustment to the shutter speed, BLC ratio and area

Gain control, white balance

It also be able to adjust some advanced functions like motion, privacy masking, mirror, and gamma ratio

Privacy masking: apply 4 masking area on the image, each area is programmable with size, position and color setting

Backlight compensation: in order to make it works better with the license plate recognition, EL-C216-OR allows user to set the BLC area with up to 64 grid on the image and adjustable ratio to set the image brightness

Motorized IR filter:

This function allows the customer to have true color image at day time

The IR filter will only moves in with the illumination is below 10 lux

It enable EL-C216-OR a true day/night camera

Adjustable shutter speed:

The shutter speed of EL-C216-OR is adjustable

It ranges from 1/60 (1/50 to 1/100K)

It enables the camera to capture clear license plate of the vehicle at different speed

Optional device:

40m IR outdoor housing with heater and fan

10 to 120mm DC auto iris lens

Download Detail Specification http://www.elitar.com/ppdtView.asp?nid=168
