• 4.3” color TFT LCD

• Powered by PoE or power adapter (DC12V/2A)

• Open the door by face recognition (10,000 users)

• Liveness detection

• Open the door by IC card (100,000 users)

• Support SIP 2.0 protocol, easy integration with other SIP devices

• Easy integration with elevator control system

Physical Property:

System: Android

RAM: 512MB

ROM: 8GB

Front Panel: Aluminum

Button: Mechanical

Power Supply: PoE (802.3af) or DC12V/2A

Standby Power: 3W

Rated Power: 10W

Camera: 2MP, CMOS

IR Sensor: Support

Door Entry: Face, IC card(13.56MHz), PIN code, NFC

IP Rating: IP65

Installation: Flush mounting

Dimension: 380 x 158 x 55.7mm

Working Temperature: -40℃ - +55℃

Storage Temperature: -40℃ - +70℃

Working Humidity: 10%-90% (non-condensing)

Display:

Display: 4.3-inch TFT LCD

Resolution: 480 x 272

Audio & Video:

Audio Codec: G.711

Video Codec: H.264

Video Resolution: up to 1920 x 1080

Light Compensation: LED white light

Networking:

Protocol: SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPV4, ARP, ICMP

Port

Wiegand Port: Support

Ethernet Port: 1 x RJ45, 10/100 Mbps adaptive

RS485 Port: 1

Relay Out: 1

Exit Button: 1

Door Magnetic: 1
