• 7-inch capacitive touch screen

• Open the door by face recognition (10,000 users)

• Liveness detection

• Open the door by IC card (100,000 users)

• Support SIP 2.0 protocol, easy integration with other SIP devices

• Easy integration with elevator control system

Physical Property

System:Android

RAM:2GB

ROM:8GB

Front Panel:Aluminum

Power Supply:DC12V/2A or PoE (External PoE)

Standby Power:5W

Rated Power:25W

Camera:2MP, CMOS

IR Sensor:Support

Door Entry:Face, IC card(13.56MHz), PIN code, NFC

IP Rating:IP65

Installation:Surface mounting

Dimension:227 x 122 x 20 mm

Working Temperature:-40℃ - +55℃

Storage Temperature:-40℃ - +70℃

Working Humidity:10%-90% (non-condensing)

Display:7-inch TFT LCD

Screen:10.1-inch capacitive touch screen

Resolution:1024 x 600

Audio Codec:G.711

Video Codec:H.264

Video Resolution:up to 1920 x 1080

Light Compensation:LED white light

Protocol:SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPV4, ARP, ICMP

Port

Wiegand Port:Support

Ethernet Port:1 x RJ45, 10/100 Mbps adaptive

RS485 Port:1

Relay Out:1

Exit Button:1

Door Magnetic:1
