System:Linux

Front Panel:Aluminum

Button:Mechanical

Power Supply:PoE (802.3af) or DC12V/2A

Standby Power:1.5W

Rated Power:9W

Camera:2MP, CMOS

Door Entry:IC card(13.56MHz), ID card(125kHz), PIN code, NFC

IP Rating:IP65

IK Rating:IK08

Installation:Flush Mounting & Surface Mounting

Flush Mounting Dimension:295 x 133 x 63.5 mm

Surface Mounting Dimension:295 x 133 x 42.7 mm

Working Temperature:-40℃ - +55℃

Storage Temperature:-40℃ - +70℃

Working Humidity:10%-90% (non-condensing)

Display

Display:4.3-inch TFT LCD

Resolution:480 x 272

Audio & Video

Audio Codec:G.711

Video Codec:H.264

Video Resolution:1280 x 720

Viewing Angle:110°（H）

Light Compensation:LED white light

Networking

Protocol:ONVIF, SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPV4, ARP, ICMP

Port

Wiegand Port:Support

Ethernet Port:1 x RJ45, 10/100 Mbps adaptive

RS485 Port:1

Relay Out:3

Reset Button:1

Exit Button/Door Magnetic:4

Door Magnetic:1
