• 8 onboard wired zones • Supports 1-way siren control and 2-way MOS transistor outputs on the control panel • With the expansion module (consists of 8 input modules and 8 output modules), alarm input and alarm output channels are increased to 72 and 82 respectively • Outputs operation follows system events, zone events, area, link and scheduling programs • 1 case tamper port and 1 leave-wall tamper port for the control panel • 1 siren tamper input port • Up to 8 areas, and every area with 2 partitions • Up to 8 keypads • Up to 100 users with 8 authority levels for different users (Supervisor, Manager, Master, User, Temporary, Duress, Patrol, and Technician) • 1000 event logs • Supports more than 11 zone types • 7 sorts of zone terminations, including closed-circuit (NC), open-circuit (NO), end-of-line (EOL) resistors, double end-of-line (DEOL) resistors, triple end-of-line (3DEOL) resistors, inertial type for vibration detector and pulse type for roller shutter • Configurable zone resistance (2K7, 4K7, and 6K8) • 2 RS-485 ports for keypad connection and extended connections • PSTN port for alarm event report, supporting CID (Contact ID) • 3 telephone numbers for monitor station (PSTN), 8 telephone numbers for vocal message, and 8 telephone numbers for SMS • GSM/GPRS/LTE network ports for events SMS reporting and remote control, events vocal message reporting by dialing and remote control, and mobile phone app connection ability when Ethernet connection failed • 10/100M self-adaptive Ethernet port • Supports abnormality alarm, including network disconnection alarm, PSTN fault alarm, tampering alarm, low battery alarm, battery loss alarm, power loss alarm, and keyboard fault alarm • In-field firmware upgradable • App-based system control through DMSS • Arm and disarm areas with RFID cards • Supports customized access to third-party platforms with SIA
