SG-TM308 is a new launch digital transmitter module from SAFE GUARD company which adopting of the latest COFDM modulation and H.265 video coding technology that support multiple IP input with triple video interfaces (HDMI/SDI/CVBS), and is capable for non-line-of sight (NLOS) transmission. It is highly integrated with ultra-linear digital predistortion RF design that set high-definition coding, digital modulation, full-band RF output in one and comes with narrowband(1MHz), low latency, transparent data long-distance transmission which can help you to achieve a long-distance wireless links required, especially for military, security, public security, and fire protection applications. It is widely used in high standard unmanned control system and intelligent control equipment for multi-channels video transmission.

__________________________________________________________________________________________________________________________

Features

H.265 high-efficiency compression

COFDM ultra-narrow band modulation technology

Triple video inputs of HDMI/SDI/CVBS

Full HD definition 1080i/P, adaptive multiple video format input

4-channel UDP unidirectional network and video streaming sync

Full-band / ultra-narrow band / multi-bandwidth adjustment

Transparent network protocol and high capacity of transfer rate

Configuration preset supported

128-bit dynamic AES encryption

Small size, light weight, portable

Strong heat dissipation with heat sink type of aluminum housing

__________________________________________________________________________________________________________________________

Specifications

Model SG-TM308

Working voltage DC 6~17V

Video input SDI/HDMI/CVBS

UART Transparent TTL serial one-way data transmission

LAN 4 UDP ports

Transfer rate 30Mbits/S_RJ45 & 115200bps_RS232

RF bandwidth 1/2/4/8M

Frequency 300MH~2500MHz, 1 MHz tuning step

Encryption 128-bit dynamic AES

FEC 1/2, 2/3, 3/4, 5/6, 7/8

Guard interval 1/32, 1/16, 1/8, 1/4

Video compression H.265

Modulation COFDM, QPSK, QAM16, QAM64

RF output IPX

Parameter control Control panel

Dimension 78*48*20mm

Weight 115g
