- Fingerprint Module: Optical

- Fingerprint Templates: 9600

- LCD (128x64 Dot-Matrix): Yes

- Touch Sense Keys (16): Yes

- Type of Card: Smart and Proximity

- USB: Yes

- Communication: Ethernet and RS-485

- Events Buffer: 50000

- Communication Speed: 10/100Mbps on Ethernet and 115.2Kbps on RS-485

- External Reader: 1 Port for Card or Fingerprint Reader

- External Reader: Interfaces RS-232 and Wiegand

- External Reader Power: 12VDC@0.5A

- Exit Switch Port: Yes

- Door Status Sense: Programmable NO, NC, Supervised

- Door Lock Relay: Relay SPDT, Form C, 1A@30VDC

- Door Lock Power: Internal12VDC@0.5A or External

- Auxiliary Input Port: Programmable NO, NC, Supervised

- Auxiliary Output Relay: Relay SPDT, Form C, 1A@30VDC

- Tamper Detection: Yes

- Buzzer: Yes

- LED Indication: 4 LEDs (Status, Alarm, Allowed and Denied)

- CPU: 32-Bit Micro-Controller

- Memory: 128KB SRAM, 512KB Internal, Flash+2MB External Flash

- Input Power 12VDC@2A

- Dimensions (WхHхD): 100×220×55mm (3.9”х8.7”х2.2”)

- Weight: 0.49Kg and 1.07Lbs

- Environment: -100 C to +500C (140F to 1220F), 5% to 95% RH Non-Condensing
