Image Sensor: 1/3” Color Sharp CCD

Effective Pixels: PAL:500(H)x582(V)/NTSC:510(H)x492(V)

Sensing Area: 4.9mm × 3.7mm

Horizontal Resolution: 420TVL

Signal System: PAL / NTSC

S/N Ratio: More than 48dB (AGC OFF)

Shutter Speed: 1/50 (1/60) to 1/100,000 sec

White Balance: Automatic White Balance (3200-10000K)

AGC: Auto

Backlight Compensation: Auto

Synchronization System: Internal

Minimum Illumination: 0.2Lux / F1.2, 0LUX with IR On

Video Output: 1.0Vp to p at 75ohm

Power Source: DC12V

Power Consumption: 120mA (IR Off), 400mA (IR On)

Lens Mount: 6mm Board Lens

Infrared luminary: 16pcs ?8 IR-LED

Illuminate Distance: 25M

Dimension: 76(Dia.) x 135(L) mm

Weight: 350g

Material: Aluminum

WAterproof Rating: IP66
