Image Sensor: 1/3” Color Sony CCD

Effective Pixels: PAL:500(H)x582(V)/NTSC:510(H)x492(V)

Sensing Area: 4.9mm × 3.7mm

Horizontal Resolution: 420TVL

Signal System: PAL / NTSC

S/N Ratio: More than 48dB (AGC OFF)

Shutter Speed: 1/50 (1/60) to 1/100,000 sec

White Balance: Automatic White Balance

Minimum Illumination: 0.5 Lux / F1.2

Video Output: 1.0Vp to p at 75ohm

Gamma: 0.45

Power Source: DC12V+10%, Optional: Dual Voltage

Power Consumption: 85mA

Lens Mount: 3.5-8mm Manual VarifocalLens

(Optinal: 3.6/6mm Board Lens)

Dimension: 112(Dia.) × 82(H) mm

Weight: 470g

Material: Specific Aluminum Alloy

Waterproof Rating: IP65
