Image Sensor: 1/3” Color Sony CCD

Effective Pixels: PAL:752(H)x 582(V)/NTSC:768(H)x494(V)

Sensing Area: 4.9mm × 3.7mm

Horizontal Resolution: 520TVL

Signal System: PAL / NTSC

S/N Ratio: More than 52dB (AGC OFF)

Shutter Speed: 1/50 (1/60) to 1/100,000 sec

White Balance: Automatic White Balance

Minimum Illumination: 0.8LUX / F1.2

Video Output: 1.0Vp to p at 75ohm

Viewing Angle: 45°

Power Source: DC12V+10%

Power Consumption: 120mA

Lens Mount: 3.5-8mm Manual Varifocal Lens

Dimension: 119(Dia.) ×110(H) mm

Weight: 670g

Material: Polycarbonate,

Waterproof Rating: IP66
