Image Sensor: 1/3” Color Sony CCD

Effective Pixels: PAL:752(H)x582(V)/NTSC:768(H)x494(V)

Sensing Area: 4.9mm × 3.7mm

Horizontal Resolution: 520TVL

Signal System: PAL / NTSC

S/N Ratio: More than 52dB (AGC OFF)

Shutter Speed: 1/50 (1/60) to 1/100,000 sec

White Balance: Automatic White Balance

Minimum Illumination: 0LUX with IR On

Video Output: 1.0Vp to p at 75ohm

Viewing Angle: 45°

Power Source: DC12V+10%

Power Consumption: 120mA (IR OFF), 400mA (IR On)

Lens Mount: 6mm Board Llens

Infrared Luminary: 14pcs ?5 IR-LED

Illuminate Distance: More than 20M

Dimension: 140(Dia.) × 110(H) mm

Weight: 400g

Material: Plastic
