Features: wirelessconnection,Ultra-low power consumption,Remote active awakening,Quick start. Guestswill be able to make video voice calls and take short videos. The owner willnot need to open the door to know the information

Wake up the way:The doorbell button awakens,PIR body detection wake up,Mobile phonecall

Alarm push:Pushfor 1 second

Multiple users are online simultaneously

Dynamic DNS:Bring your own dynamic domain name

Processor:Apowerful, high-performance, programmable media HiSilicon processor withbuilt-in ARM926 @max. 440MHz and high-speed video coprocessor

Sensor:1/4inch 720p scan CMOS sensor

Sensor performance:Support automatic white balance, automatic gain control,automatic backlighting compensation

SNR:≥39dB

LUX:0.8Lux/F1.4(Color pattern),0.3Lux/F1.4(Black and white pattern)

Lens/visual Angle:1.7mm@F2.4/166°

LED:Doublefilter automatic switching, six 850 - nm Φ 28 mil high power infrared lamp,night vision 10 meters

IR control:IR opens night vision,Automatic detection of infrared and ICR;IRshuts the night vision function off the infrared and the ICR is fixed in dailyviewing mode

Video:CompressionstandardH.264 Main Profile/H.264 BaselineProfile/MJPEG/JPEG Baseline

More stream:720P/24fps+VGA/30fps+QVGA/30fps+720P@1fsJPEG snap

Resolution:1080*720

Audioinput:1 channel built-in - 48dB microphone

Audio output:Built-in speaker (8 Ω 1 w)

Interphone:Two- way voice - speak, bring back the echo cancellation

Compression standard/ code rate:ADPCM/32kbps

Network protocol:TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP,P2P

Wireless network:802.11b/g/n

Wireless network security:WPS Security encryption

Wireless connection:One-button WIFI configuration

Video mode:Mobiledetection video, doorbell button trigger video, manual video

Storage:TheTF card stores the maximum support for 32gb

Power: Battery power supply two section18650 core international general

Power consumption: Standby current 400 uAworking current 200MA

Work environment:Working temperature:-10 ~ 50 ℃, humidity is < 95%

Installation:Door wall mounting

Material:ABS

Product size190*117*75MMLong * width *height

Product weight:330g No battery

Packing size:/60.5*40*40CM

Packing list: one outside doorbell, one indoor ring,one user manual, Screws
