◊ Adopts luminance separation and 3D DNR technology, high-resolution, better image

◊ No delay, real-time transmit video up to 500M(720P/960P) or 300M(1080P)

◊Supports D1/960H, ISP and TX 2 in 1, compatible with analog Matrix/Distributor etc.

◊ Built-in double IR-CUT filter, No color deviation

◊ Adopts Long-life and SMART 3pieces big Epistar IR Arrays, IR range up to 60meters

◊6mm/F1.2 big Megapixel lens, 4mm,8mm,12mm,16mm/F1.2 or 25mm/F1.4 optional

◊ Support BLC (backlight compensation), auto white balance, color reproduction and high, less noise, illumination lower, more stable performance

◊ Adopts double glass, the image more clear and bright

◊ 720p/960p/1080p and HD-AHD/HD-CVI/HD-TVI optional

◊ Aluminum housing, Weather proof,IP66

Specification:

Model

DLX-HB3A10

DLX-HB3A13

DLX-HB3A20

Pixel

1280x720

1280X960

1920X1080

Signal System

PAL/NTSC

Lens

Fixed 6mm/F1.2 Megapixel lens (4,8,12,16mm/F1.2 or 25mm/F1.4 optional)

Min. Illumination

0LUX(IR ON)

IR

3pieces big Epistar IR Arrays, IR range 60M

BLC

Auto

AGC

Auto

Electronic shutter

1/50(1/60)s to 1/100,000s

S/N

>69dB

Gamma correction

>0.45

Video output

1.0Vp- p75Ω（BNC)

Power

DC12V ±10%

Water proof

IP66

Material

Aluminum

Operating Conditions

-18 °C - 50 °C, Humidity 90% or less (non-condensing)

Dimension

170x100x85mm

Weight

600g
