Features:
◊ 1/3" Megapixel HD CMOS sensor, Support resolution: 720P/960/1080P
◊ H.264 compression, Support Dual Stream, smooth and clear image, Suit to local/remote/cross regional Watch
◊ Support P2P(peer to peer) transmission without router setting or mapping
◊ Support Max.64G SD for store photo and video. Has record management function, user can set time of automatic video recording, also can automatic video recording via motion detecting. Beside,user can remote download video files of SD card by network
◊ Support IR-CUT double-filter, IR range up to 50meters,Image no distortion and no color cast
◊ Support UPNP-plug and play function
◊ 1.44mm fish eye lens, Horizontal: 180°
◊ Support Android, iPhone etc mobiles watch directly(better quality video when using H.264 format)
◊ Support IE, Firefox, Safar ect. browsers
◊ Support remote watch video and record by internet
◊ Support TCP/IP,HTTP,SMTP,RTSP,FTP,DHCP,DDNS,NTP etc network protocol
◊ Support motion detecting, send alarm signals by email or FTP upload pics etc., Also can send alarm information to alarm server
◊ Support remote watch video and record by internet
◊ Use multi-level usernames and passwords
Specification
CPU
Operation system
Windows, Linux, iOS, Android etc.
Processor
32Bit RSIC Embedded Processor
Sensor&Lens
Sensor
1/3" Megapixel CMOS
performance
Automatic BLC, White Balance and Gain Control
Min. Illumination
Color:0.8Lux/F1.4, W/B:0.01LUX/F1.0
S/N
>50dB
Lens
1.44mm
Video
Compression
H.264 Main Profile, MJPEG/JPEG Baseline
Resolution
1080P/960P/720P,VGA(640*480),QVGA(320*240)
Frames per sec.
1-25fps
Image adjustment
Saturation, brightness, contrast
Night vision
IR
3pieces IR LEDs, IR range50M, Automatic IR-CUT
Network
Internet protocol
TCP/IP,HTTP,ICMP,DHCP,FTP,SMTP, PPPoE, RTSP
Wireless
Wi-Fi 802.11b/g/n
Alarm
Motion detecting
Sensitive motion detecting
Alarm inform
Support E-mail, FTP upload and pop - up alarm on mobile
Physical indexes
Power supply
DC12V 2A
Working Environment
-10~50 °C/ 95% RH
Material
Metal
Size&weight
230x100mm,400g
