◊Adopts Embedded RTOS design,32bit DSP CPU, Integrated high performance video encode accelerator, Super high performance RTOS

◊Dual stream, Video code rate (64kbps-8Mbps) can be uninterrupted adjust

◊Support TCP/IP, support IE browser/Android/Iphone etc.

◊Support POE function

◊Adopts double glass, the image more clear and bright

◊Built-in double IR-CUT filter, No color deviation

◊Adopts Long-life 24pieces IR lights, IR range up to 30meters

◊2.8-12mm varifocal manual lens

◊Adopts double glass, the image more clear and bright

◊ 2Mp 1920x1080,1/2.5” CMOS

◊ Plastic housing

Specification:

Signal System PAL/NTSC

Lens 2.8-12mm manual

Min. Illumination 0LUX(IR ON)

IR 24pieces IR lights, IR range 30M

BLC Auto

AGC Auto

WDR Auto

Electronic shutter 1/50(1/60)s to 1/100,000s

S/N >69dB

Gamma correction >0.45

Video output 1.0Vp- p75Ω（BNC)

Ethernet port 1 RJ45 Ethernet port ,10/100M,POE

Video process H.264 code, Dual Stream, AVI format, 64k~8Mpbs adjustable

Protocol ONVIF, RTSP,PPPoE,DHCP,TCP/IP,HTTP,UDP,RTP/RTCP,UPNP,FTP,DDNS

Power DC12V ±10%

Material Plastic

Operating Conditions -18 °C - 50 °C, Humidity 90% or less (non-condensing)
